Field Pup

The Field Pup is rated for off road use but runs smoothly on the roadway.
It has UL explosion proof heavy-duty pumps, Good Year UL hose with static wire, and automatic shut-off nozzles by Catlow.
The Field Pup is manufactured using very heavy duty drop axles and suspension and 6-channel for long product life and durability. The trailer rating is 170% of gross trailer weight for the 500-gallon unit.The trailer meets or exceeds DOT requirements for heavy duty axles, tires, brakes, lights, reflectors, safety equipment, the tank for gauge of steel, baffle to headwall distance, safety vent, drain, etc. The 4 corner D-rings on frames provide weather or transport tie-down capability.
The load strength of each ring is 6000#, for a total rating of 24000#. The unit is equipped with a tank fuel level gauge and a tank mounted hose rack holding up to 30′ of hose.

Field Pup fuel trailers are built with safety in mind:

  • A fusible plug is used on all fuel trailers
  • The Tank is bolted into a heavy cross member cradle, offering protection on all four sides of the trailer. Additional stops on all four corners prevent a forward/backward motion of the tank
  • Tank is grounded to the frame.
  • Pump is UL listed explosion proof.
